BX80701G5905 - CPU CELERON G5905, 3.5GHz, SOCKET 1
Specyfications
CPU Specifications
Total Cores
2
Total Threads
2
Processor Base Frequency
3.50 GHz
Cache
4 MB Intel® Smart Cache
Bus Speed
8 GT/s
TDP
58 W
Memory Specifications
Max Memory Size (dependent on memory type)
128 GB
Memory Types
DDR4-2666
Max of Memory Channels
2
Max Memory Bandwidth
41.6 GB/s
GPU Specifications
GPU Name
Intel® UHD Graphics 610
Graphics Base Frequency
350 MHz
Graphics Max Dynamic Frequency
1.05 GHz
Graphics Video Max Memory
64 GB
4K Support
Yes, at 60Hz
Max Resolution (HDMI)
4096x2160@30Hz
Max Resolution (DP)
4096x2304@60Hz
Max Resolution (eDP - Integrated Flat Panel)
4096x2304@60Hz
DirectX* Support
12
OpenGL* Support
4.5
Intel® Quick Sync Video
Yes
Intel® InTru™ 3D Technology
Yes
Intel® Clear Video HD Technology
Yes
Intel® Clear Video Technology
Yes
Expansion Options
Scalability
1S Only
PCI Express Revision
3.0
PCI Express Configurations
Up to 1x16, 2x8, 1x8+2x4
Max of PCI Express Lanes
16
Package Specifications
Sockets Supported
FCLGA1200
Max CPU Configuration
1
Thermal Solution Specification
PCG 2015C
TJUNCTION
100°C
Package Size
37.5mm x 37.5mm
Advanced Technologies
Intel® Optane™ Memory Supported
Yes
Intel® Thermal Velocity Boost
No
Intel® Turbo Boost Max Technology 3.0
No
Intel® Turbo Boost Technology
No
Intel® Hyper-Threading Technology
No
Intel® Transactional Synchronization Extensions
No
Intel® 64
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2
Idle States
Yes
Enhanced Intel SpeedStep® Technology
Yes
Thermal Monitoring Technologies
Yes
Intel® Identity Protection Technology
Yes
Security & Reliability
Intel® AES New Instructions
Yes
Secure Key
Yes
Intel® Software Guard Extensions (Intel® SGX)
Yes with Intel® ME
Intel® OS Guard
Yes
Intel® Trusted Execution Technology
No
Execute Disable Bit
Yes
Intel® Boot Guard
Yes
Intel® Stable IT Platform Program (SIPP)
No
Intel® Virtualization Technology (VT-x)
Yes
Intel® Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® VT-x with Extended Page Tables (EPT)
Yes
